Low Noise AC/DC Power Supply
Daitron AC/DC switching power supply features Ultra Low Noise equivalent to linear type of power supply products even in a small footprint, high efficiency, less components required and cost effective price range to high end noise sensitive applications in Medical and Industrial markets.
Design Engineers can "Get rid of linear power supply" for their new designs.
Product Overview:
Design Engineers can "Get rid of linear power supply" for their new designs.
- Why a "Daitron Power Supply"? - Get rid of your linear power supply!
Features
- Ultra Low Ripple & Noise
- Low Leakage Current
- Small & Light weight
- High Efficiency
- RoHS Free, Vinyl Chloride Free, Halogen Free
- Meet Safety Standards (UL, CSA, EN, PSE)
Product Overview:
| Product Series | LFS50A | LFS150A | PFS300A |
| Vin (50/60Hz,100-240VAC) | standard | standard | standard |
| Output (W) | 50 | 150 | 300 |
| Power Factor 100V/200V | 0.97/0.86 | 0.98/0.90 | 0.98/0.93 |
| Ripple Noise (mVp-p typ) | 10 | 10 (13 for 48VDC) | 10 |
| Leakage current (mA @264VAC) | 0.15 | 0.15 | 0.2 |
| OCP | > 110% on output | > 110% on output | > 110% on output |
| OVP | > 115% on input | > 115% on input | > 115% on input |
| Remote Enable | standard | standard | standard |
| Remote Sensing | standard | standard | standard |
| Remote Voltage Adjustment | standard | standard | N/A |
| DC output options 5 | ■ | ■ | N/A |
| 12 | ■ | ■ | ■ |
| 15 | ■ | ■ | ■ |
| 24 | ■ | ■ | ■ |
| 30 | ■ | ■ | ■ |
| 48 | ■ | ■ | ■ |
| CE | standard | standard | standard |
| UL/CSA | standard | standard | standard |
| (UL/EN 60601-1, UL/EN 60950-1) |
